Power quality analyzer PQI96

Overview

PQI96 is a modern digital measurement instrument, providing accurate three-phase measurements of AC electrical quantities. It also enables power quality assessment according to present standards.

Areas of application

The  Power Quality Analyzer PQI96 is intended for continuous measurements of electrical power and power quality parameters in three-phase AC networks. It can be used to control the conformity of power quality with EN50160 norms.

Features

Multifunctionality
Device carries out measurements of harmonics, interharmonics, unbalance, flicker, active, reactive and apparent powers, phase angles of fundamental and harmonic components and much more.

High accuracy and standard compliance
All power quality measurements  are made according to IEC 61000-4-30 ed.2 Class A. Harmonic and interharmonic components are measured according to IEC 61000-4-7 Class I. Flicker is measured according to IEC 61000-4-15 Class F3.

Very compact form-factor (96 x 96 x 75 mm)
enables fast and easy installation into distributing panels.

Increased LED indicator height (25 mm)
provides comfortable local meter readings.

Ethernet based synchronization (NTP/PTP)
does not require additional synchronization circuits and is accurate up to ±1µs.

Competitive price
compared to existing power quality instruments.

Measurements

  • Power frequency
  • Voltage and current magnitudes
  • Flicker perceptibility
  • Dips, swells, interruptions
  • Voltage unbalance
  • Voltage harmonics
  • Voltage interharmonics
  • Under- and overdeviation
  • Relative phase angles
  • Active, reactive, apparent powers
  • Active and reactive energies





Specifications
Documentation
Overall drawings
Related products

Type

Dimensions, mm

Weight, kg, max

PQI96

96 х 96 х 77

0,7

Main parameters

Measurements

rated voltage: 57,73 (100) or 230 (400) V

rated current: 1 or 5 А

current/voltage measurement frequency: 42.5...57.5 Hz

Communication ports

Ethernet (10/100 BASE TХ or 100 BASE FX), EIA RS485

Type of display

7-digit LED (3 lines of 4 digits), digit height 20 mm and 14 mm

Temperature range (operating)

from -40˚С to +55˚С, ANSI/IEC 60529 IP51

Electromagnetic compatibility

According to GOST R 51317.6.5, ISCRI 22 for Class A

Effective voltage and current values;

Active/reactive/full power;

Reduction of active/reactive/full power;

Voltage and current angular curves.

According to GOST R 8.655

Power supply

from 90 to 264 V AC, (50 ± 0.5) Hz or from 130 to 370 V DC

Calibration interval

10 years

Guarantee period

36 months

PQI parameters

Power quality measurements

Power frequency

Voltage and current magnitudes

Flicker perceptibility

Dips, swells, interruptions

Voltage unbalance

Voltage harmonics

Voltage interharmonics

Under- and overdeviation

Relative phase angles

Active, reactive, apparent powers

Active and reactive energies

Power quality: IEC 61000-4-30 : Class A

Harmonics and Interharmonics: IEC 61000-4-7 : Class I

Flicker: IEC 61000-4-15 : Class F3

Metrological characteristics

According to GOST 30804.4.30-2013, GOST 32144-2013, GOST R 51317.4.15-2012, GOST 30804.4.7-2013, GOST R 8.655-2009 (power quality)

Interfaces

Remote HMI and Control

HTTP (WEB interface)

Communication protocols

IEC 60870-5-104 (Ethernet),

IEC 60870-5-101 (EIA RS-485),

IEC 61850-8-1

Integration in power quality indices (PQI) control system

HTTP (integration in PQI visualization and monitoring software package supplied in completion with the meter)

Synchronization

NTP (RFC 5905), PTP (IEEE 1588)

Order form

PQI96 – b – с – d – e – f – g – h – i

b – rated voltage:
– line voltage – 100 V, 400 V;
– transformation ratio of voltage (rated secondary voltage value is 100 V);

c – rated current:
– phase current – 1.0 А; 5.0 А;
– transformation ratio of current (nominal secondary current value is 1 A, 5 A);

d – the type of the main Ethernet interface:
– 1REО – an interface Ethernet («optics», «Optics»);
– 1REC – an interface Ethernet («copper», «twisted pair»);

е – the symbol of the presence of an additional interface RS485 (only for the device having option REC):
- RS - RS485 interface is available;
- x - RS485 interface is not available;

f – symbol of the measuring circuit:
- 3W - for three-wire connection scheme,
- 4W - for four-wire connection scheme;

g – color of the indicators:
– R – red indicators,
– G – green indicators,
– Y – yellow indicators;

h – temperature range (operating):
– (-40...+55° C);

i – special version:
– otherwise, this parameter is not specified

Ordering example

PQI96 – 100V – 1А – 1RЕС– х – 3W – R – (-40...+55° C) TU 25-7504.227-2014
PQI96 with the following characteristics: rated voltage of 100 V, rated current of 1.0 А, interface Ethernet (“copper”), three-wire connection scheme, red indicators, for operation at temperature of minus 40 to plus 55 °С.
